Mercury Elite 2200U Smart UPS – Technical Specification

This Uninterruptible Power Supply (UPS) is a Line-Interactive unit designed to protect equipment from power fluctuations, surges, and outages, ensuring safe shutdown or continued operation of connected devices.

1. General & Performance

2. Input Specifications

3. Output Specifications

Attribute	Specification
Output Voltage (AC Mode)	Synchronized with Utility Power
Output Voltage (Battery Mode)	$220\text{ VAC}\pm 10\%$
Output Frequency	$50/60\text{ Hz}\pm 1\text{ Hz}$ (Battery Mode)
Waveform (Battery Mode)	Simulated Sine Wave (Stepped Approximation)
Transfer Time	Typical $2-6\text{ ms}$ (Maximum $10\text{ ms}$)
Output Sockets	Typically $4\times$ Universal Sockets (Battery Backup)

4. Battery & Runtime

Attribute	Specification
Battery Type	Sealed Lead Acid, Maintenance-Free
Battery Configuration	$2\times 12\text{ V / 9 AH}$
Recharge Time	$6-8\text{ hours}$ recovery to $90\%$ capacity
Battery Management	Intelligent Battery Management for extended life
Typical Runtime	Up to $60\text{ minutes}$ at typical low loads (e.g., small PC, router)

5. Physical & Environmental

Attribute	Specification
Dimensions (L x W x H)	Approx. $390\times 125\times 225\text{ mm}$ (Varies slightly by variant)
Net Weight	Approx. $13.4\text{ kg}$
Operating Temperature	0∘C−40∘C
Humidity	$0-90\%$ Relative Humidity (Non-condensing)
Noise Level	Less than $45\text{ dB}$
