Mercury Elite 1200 Pro Line Interactive UPS Specification

This specification is based on the Mercury Elite 1200 Pro model, a Line-Interactive Uninterruptible Power Supply (UPS) designed to provide stable power and backup for computers, small office equipment, and home electronics.

1. General Specifications

2. Input Specifications

3. Output Specifications

Feature	Specification
Nominal Voltage	220 VAC
Voltage Regulation (Battery Mode)	$220\text{Vac}(-7\%\text{ to }+15\%)$
Waveform (AC Mode)	Pure Sine Wave (Synchronized with Utility)
Waveform (Battery Mode)	Simulated Sine Wave
Transfer Time	Typical $4-8\text{ms}$
Output Sockets	4 x Universal Sockets (Battery Backup)

4. Battery & Charging

Feature	Specification
Battery Type	Sealed Lead Acid, Maintenance Free
Battery Rating	$2\times 12\text{V}/7.5\text{Ah}$
DC Voltage	24 VDC
Recharge Time	6–8 hours to $90\%$ after complete discharge
Charging Current	Approximately $1\text{A}$ at normal mode
Overcharge Protection	Stops charging at $29\text{V}\pm 0.2\text{V}$

5. Protection & Environmental

Feature	Specification
Protection	Overload, Short Circuit, Battery Deep Discharge, Overcharge
Audible Alarms	Battery Mode, Low Battery, Overload, Fault
Operating Temperature	$0\text{°C}-40\text{°C}$
Humidity	$0-90\%$ (Non-condensing)
Noise Level (at 1M)	Less than $45\text{dB}$
Unit Weight	$8.6\pm 0.3\text{ Kg}$
Unit Dimensions ($\text{L}\times \text{W}\times \text{H}$)	$338\times 149\times 162\text{mm}$ (Approximate)
